Datasheet, Volume 2 259
Processor Configuration Registers
6RO 1b
Protected High-Memory Region (PHMR)
0 = Indicates protected high-memory region is not supported.
1 = Indicates protected high-memory region is supported.
DMA-remapping hardware implementations on Intel TXT platforms
supporting main memory above 4 GB are required to support protected high-
memory region.
5RO 1b
Protected Low-Memory Region (PLMR)
0 = Indicates protected low-memory region is not supported.
1 = Indicates protected low-memory region is supported.
DMA-remapping hardware implementations on Intel TXT platforms are
required to support protected low-memory region.
4RO 1b
Required Write-Buffer Flushing (RWBF)
0 = Indicates no write-buffer flushing is needed to ensure changes to
memory-resident structures are visible to hardware.
1 = Indicates software must explicitly flush the write buffers to ensure
updates made to memory-resident remapping structures are visible to
hardware. Refer to the VTd specification for more details on write buffer
flushing requirements.
3RO 0b
Advanced Fault Logging (AFL)
0 = Indicates advanced fault logging is not supported. Only primary fault
logging is supported.
1 = Indicates advanced fault logging is supported.
2:0 RO 00b
Number of domains supported (ND)
000b = 4-bit domain-IDs with support for up to 16 domains.
001b =6-bit domain-IDs with support for up to 64 domains.
010b =8-bit domain-IDs with support for up to 256 domains.
011b =10-bit domain-IDs with support for up to 1024 domains.
100b =12-bit domain-IDs with support for up to 4K domains.
100b =14-bit domain-IDs with support for up to 16K domains.
110b =16-bit domain-IDs with support for up to 64K domains.
111b =Reserved.
B/D/F/Type: 0/2/0/GFXVTBAR
Address Offset: 8–Fh
Reset Value: 00C0000020230272h
Access: RO
Bit Attr
Reset
Value
Description
