Intel
®
QuickPath Architecture System Address Decode Register Description
342 Datasheet, Volume 2
3.4 PCI Standard Registers
These registers appear in every function for every device.
3.4.1 VID—Vendor Identification Register
The VID Register contains the vendor identification number. This 16-bit register,
combined with the Device Identification Register uniquely identifies the manufacturer
of the function within the processor. Writes to this register have no effect.
3.4.2 DID—Device Identification Register
This 16-bit register combined with the Vendor Identification register uniquely identifies
the Function within the processor. Writes to this register have no effect. See
Section 3.2 for the DID of each processor function.
Device: 0
Function: 0–1
Offset: 00h
Device: 2
Function: 0–1,
Offset: 00h
Bit Type
Reset
Value
Description
15:0 RO 8086h
Vendor Identification Number
The value assigned to Intel.
Device: 0
Function: 0–1
Offset: 02h
Device: 2
Function: 0–1,
Offset: 02h
Bit Type
Reset
Value
Description
15:0 RO
*See
Section 3.2
Device Identification Number
This field identifies each function of the processor.
