Processor Configuration Registers
254 Datasheet, Volume 2
2.17.2 GFXPLL1—GFX PLL BIOS
This is the GFX PLL BIOS register. See latest BIOS specification for more details.
1RO 0b
IGD VGA Disable (IVD)
0 = Enable. Device 2 (IGD) claims VGA memory and IO cycles, the Sub-
Class Code within Device 2 Class Code register is 00.
1 = Disable. Device 2 (IGD) does not claim VGA cycles (Memory and IO),
and the Sub- Class Code field within Device 2 function 0 Class Code
register is 80.
BIOS Requirement: BIOS must not set this bit to 0 if the GMS field (bits
6:4 of this register) pre-allocates no memory. This bit MUST be set to 1 if
Device 2 is disabled either using a fuse or fuse override (CAPID0[38] = 1) or
using a register (DEVEN[3] = 0).
0RO 0bReserved
B/D/F/Type: 0/2/0/PCI
Address Offset: 52–53h
Reset Value: 0030h
Access: RO
Bit Attr
Reset
Value
Description
B/D/F/Type: 0/0/0/MCHBAR
Address Offset: 2C32–2C33h
Reset Value: 0434h
Access: RO, RW
Bit Attr
Reset
Value
Description
15:11 RO 00b Reserved
10:8 RW 100b
Core Sampler Clock Pre-Div (CSPRE)
The CS pre-divider encoding is
000 = 2
001 = 2
010 = 2
011 = 3
100 = 4
101 = 5
110 = 6
111 = 6
7:6 RO 00b Reserved
5:4 RW 10b
Core Render/Sampler Clock Post-Div (GFXPOST)
Select CR/CS clocks output
sel1 sel0 CRpostdiv
0 0 div1
0 1 div2
1 0 div4
1 1 div8
3RO 0bReserved
2:0 RW 101b
Core Render Clock Pre-Div (CRPRE)
The CR pre-divider encoding is:
000 = 2
001 = 2
010 = 2
011 = 3
100 = 4
101 = 5
110 = 6
111 = 6
