Processor Configuration Registers
194 Datasheet, Volume 2
2.15.5 GSTS_REG—Global Status Register
This register reports general DMA-remapping hardware status.
B/D/F/Type: 0/0/0/VC0PREMAP
Address Offset: 1C–1Fh
Reset Value: 00000000h
Access: RO
Bit Attr
Reset
Value
Description
31 RO 0b
Translation Enable Status (TES)
This field indicates the status of DMA-remapping hardware.
0 = DMA-remapping hardware is not enabled
1 = DMA-remapping hardware is enabled
30 RO 0b
Root Table Pointer Status (RTPS)
This field indicates the status of the root-table pointer in hardware. This field
is cleared by hardware when software sets the SRTP field in the Global
Command register. This field is set by hardware when hardware completes
the set root-table pointer operation using the value provided in the Root-
Entry Table Address register.
29 RO 0b
Fault Log Status (FLS)
This field is valid only for implementations supporting advanced fault logging.
This field indicates the status of the fault-log pointer in hardware. This field is
cleared by hardware when software sets the SFL field in the Global Command
register. This field is set by hardware when hardware completes the set fault-
log pointer operation using the value provided in the Advanced Fault Log
register.
28 RO 0b
Advanced Fault Logging Status (AFLS)
This field is valid only for implementations supporting advanced fault logging.
This field indicates advanced fault logging status.
0 = Advanced Fault Logging is not enabled
1 = Advanced Fault Logging is enabled
27 RO 0b
Write Buffer Flush Status (WBFS)
This bit is valid only for implementations requiring write buffer flushing. This
field indicates the status of the write buffer flush operation. This field is set
by hardware when software sets the WBF field in the Global Command
register. This field is cleared by hardware when hardware completes the write
buffer flushing operation.
26 RO 0b
Queued Invalidation Enable Status (QIES)
This field indicates queued invalidation enable status.
0 = queued invalidation is not enabled
1 = queued invalidation is enabled
25 RO 0b
Interrupt Remapping Enable Status (IRES)
This field indicates the status of Interrupt-remapping hardware.
0 = Interrupt-remapping hardware is not enabled
1 = Interrupt-remapping hardware is enabled
24 RO 0b
Interrupt Remapping Table Pointer Status (IRTPS)
This field indicates the status of the interrupt remapping table pointer in
hardware.
This field is cleared by hardware when software sets the SIRTP field in the
Global Command register. This field is Set by hardware when hardware
completes the set interrupt remap table pointer operation using the value
provided in the Interrupt Remapping Table Address register.
