Datasheet, Volume 2 253
Processor Configuration Registers
2.17 Graphics Control Registers
2.17.1 MGGC—Graphics Control Register
All the Bits in this register are Intel TXT lockable.
B/D/F/Type: 0/2/0/PCI
Address Offset: 52–53h
Reset Value: 0030h
Access: RO
Bit Attr
Reset
Value
Description
15:12 RO 0h Reserved
11:8 RO 0h
GTT Graphics Memory Size (GGMS)
This field is used to select the amount of main memory that is pre-allocated
to support the Internal Graphics Translation Table. The BIOS ensures that
memory is pre-allocated only when Internal graphics is enabled.
GSM is assumed to be a contiguous physical DRAM space with DSM, and
BIOS needs to allocate a contiguous memory chunk. Hardware will drive the
base of GSM from DSM only using the GSM size programmed in the register.
0h = No memory pre-allocated. GTT cycles (Memory and IO) are not
claimed.
1h = No VT mode, 1 MB of memory pre-allocated for GTT.
3h = No VT mode, 2 MB of memory pre-allocated for GTT.
9h = VT mode, 2 MB of memory pre-allocated for 1 MB of Global GTT and 1
MB for Shadow GTT.
Ah = VT mode, 3 MB of memory pre-allocated for 1.5 MB of Global GTT and
1.5 MB for Shadow GTT.
Bh = VT mode, 4 MB of memory pre-allocated for 2 MB of Global GTT and 2
MB for Shadow GTT.
All unspecified encodings of this register field are reserved, hardware
functionality is not ensured if used.
7:4 RO 0011b
Graphics Mode Select (GMS)
This field is used to select the amount of main memory that is pre-allocated
to support the Internal Graphics device in VGA (non-linear) and Native
(linear) modes. The BIOS ensures that memory is pre-allocated only when
Internal graphics is enabled.
0h = No memory pre-allocated. Device 2 (IGD) does not claim VGA cycles
(Memory and IO), and the Sub-Class Code field within Device 2 function
0 Class Code register is 80h.
1h = DVMT (UMA) mode, 1 MB of memory pre-allocated for frame buffer.
2h = DVMT (UMA) mode, 4 MB of memory pre-allocated for frame buffer.
3h = DVMT (UMA) mode, 8 MB of memory pre-allocated for frame buffer.
4h = DVMT (UMA) mode, 16 MB of memory pre-allocated for frame buffer.
5h = DVMT (UMA) mode, 32 MB of memory pre-allocated for frame buffer.
6h = DVMT (UMA) mode, 48 MB of memory pre-allocated for frame buffer.
7h = DVMT (UMA) mode, 64 MB of memory pre-allocated for frame buffer.
8h = DVMT (UMA) mode, 128 MB of memory pre-allocated for frame buffer.
9h = DVMT (UMA) mode, 256 MB of memory pre-allocated for frame buffer.
BIOS Requirement: BIOS must not set this field to 000 if IVD (bit 1 of this
register) is 0.
3:2 RO 00b Reserved
