Package Mechanical Specifications
42 Datasheet
E
E
Figure 14. Processor Top-Side Markings Example for the Intel
®
Core™2 Duo Desktop
Processors E4000 Series with 2 MB L2 Cache
ATPO
S/N
INTEL ©'05 E4500
INTEL® CORE™2 DUO
SLxxx [COO]
2.20GHZ/2M/800/06
[FPO]
M
e4
Figure 15. Processor Top-Side Markings for the Intel
®
Core™2 Extreme Processor X6800
ATPO
S/N
INTEL ©'05
INTEL® CORE™2 EXTREME
6800 SLxxx [COO]
2.93GHZ/4M/1066/05B
[FPO]
M
e4
