26 Datasheet

Intel

Celeron

Processor up to 1.10 GHz

VCC

CORE

VCC for processor

core

800 MHz

0683h

—

1.65

—V

2, 3, 20

0686h 1.70 2, 3, 20

068Ah 1.75 2, 3, 20

850 MHz

—— —

0686h 1.70 2, 3, 20

068Ah 1.75 2, 3, 20

900 MHz

—— —

068Ah 1.75 2, 3, 20

950 MHz

—— —

068Ah 1.75 2, 3, 20

1GHz

—— —

068Ah 1.75 2, 3, 20

1.10 GHz

—— —

068Ah 1.75 2, 3, 20

REF

AGTL+ input

reference voltage

——

VTT – 2%

VTT + 2% V ± 2%, 11

1.5

Static AGTL+ bus

termination voltage

— — 1.455 1.50 1.545 V 1.5 ± 3%

Transient AGTL+

bus termination

voltage

— — 1.365 1.50 1.365 V 1.5 ± 3%

2.5

VCC for VCC

CMOS

— — 2.375 2.5 2.625 V 2.5 ± 5%

AGTL+ bus

termination voltage

— — 1.365 1.50 1.635 V 1.5 ± 9%

Baseboard

Tolerance, Static

Processor core

voltage static

tolerance level at

SC242 pins

— — –0.070 — 0.100 V 6

Baseboard

Tolerance,

Transient

Processor core

voltage transient

tolerance level at

SC242 pins

— — –0.120 — 0.120 V 6

CORE

Tolerance, Static

Processor core

voltage static

tolerance level at:

• SC242 edge

fingers

— — –0.085 — 0.100 V 7

• PPGA

processor pins

— — -0.089 — 0.100 V 8

• FC-PGA/

FC-PGA2

processor pins

— — -0.080 — 0.040 V 17

Table 5. Voltage and Current Specifications

(Sheet 2 of 5)

Symbol Parameter

Processor

Min Typ Max Unit Notes

Core Freq CPUID
