PCM-9586Onboard Intel® Celeron® M 600 EBX SBC with Audio,VGA ,LCDUsers’ Manual

PCM-9586 User’s Manual xB.16 LCD Inverter Backlight Connector (CN17) ... 82B.17 CRT Display Connector (CN13) ...

PCM-9586 User’s Manual 90Appendix C System AssignmentsC.1 System I/O PortsTable C.1: System I/O PortsAddr. range (Hex)Device000-01F DMA controller0

91 Appendix C C.2 1st MB memory mapC.3 DMA channel assignmentsTable C.2: 1st MB memory mapAddr. range (Hex) DeviceF0000h - FFFFFh System ROM*CC000h

PCM-9586 User’s Manual 92C.4 Interrupt assignmentsTable C.4: Interrupt assignmentsInterrupt# Interrupt sourceIRQ 0 Interval timerIRQ 1 KeyboardIRQ 2

93 Appendix D AppendixDOptional Extras for the PCM-9586

PCM-9586 User’s Manual 94Appendix D Optional ExtrasThe PCM-9586 requires several cables for normal operation. You can make them yourself or purchase

95 Appendix D D.2 Optional USB cable (CN25,26,27)Optional USB cable (10pin,12cm) Part no. 1703100121D.3 ATX Power Control Cable (CN15)part no.:

PCM-9586 User’s Manual 96

97 Appendix E AppendixEMechanical Drawings

PCM-9586 User’s Manual 98Appendix E Mechanical DrawingsE.1 Mechanical DrawingsFigure E.1: PCM-9586 Mech Drawing (component side)CN2CN23CN3CN5CN6CN4C

99 Appendix E Figure E.2: PCM-9586 Mech Drawing (solder side)

1 Chapter 1 CHAPTER1General InformationThis chapter gives background information on the PCM-9586.Sections include: • Introduction• Features• Speci

PCM-9586 User’s Manual 100

PCM-9586 User’s Manual 2Chapter 1 Introduction1.1 IntroductionThe PCM-9586 is a solid, general purpose single board computer (SBC) to satisfy variou

3 Chapter 1 1.3 SpecificationsStandard SBC Functions• CPU: Embedded Intel® Celeron® M 600 • BIOS: Award 512 KB Flash memory• System memory: Tw

PCM-9586 User’s Manual 4VGA/LCD Interface• Chipset: Intel 852GM (Extreme Graphics 2)• Frame buffer: Supports up to 64 MB frame buffer with system me

5 Chapter 1 • Dimensions: (L x W)203 x 146 mm (8" x 5.75")• Power supply Voltage:ATX, with Vcore 2 phase, +5V power only can work• Power

PCM-9586 User’s Manual 6Figure 1.2: Board layout: dimensions (solder side)

7 Chapter 2 CHAPTER 2InstallationThis chapter explains the setup proce-dures of PCM-9586 hardware, includ-ing instructions on setting jumpers and con

PCM-9586 User’s Manual 8Chapter 2 Installation2.1 JumpersThe PCM-9586 has a number of jumpers that allow you to configure your system to suit your a

9 Chapter 2 JP2: RS 232/422/485 SelectPINS RS-232 RS-422 RS-4851,2 Open Open Close3,4 Open

PCM-9586 User’s Manual iiCopyrightThis document is copyrighted, © 2003. All rights are reserved. The orig-inal manufacturer reserves the right to mak

PCM-9586 User’s Manual 10 2.2 ConnectorsOn-board connectors link the PCM-9586 to external devices such as hard disk drives, a keyboard, or floppy

11 Chapter 2 Table 2.2: ConnectorsLabel FunctionCN1 LAN LEDCN2 GigaLAN ConnectorCN3 Power/LED HeaderCN4 LPT ConnectorCN5 IDE 44Pin ConnectorCN6 IDE 4

PCM-9586 User’s Manual 122.3 Locating jumpers and ConnectorsFigure 2.1: Jumper & Connector (component side)CN2CN23CN3CN5CN6CN4CN27CN9CN25CN26CN11

13 Chapter 2 Figure 2.2: Jumper & Connector (solder side)

PCM-9586 User’s Manual 142.4 Setting JumpersYou may configure your card to match the needs of your application by setting jumpers. A jumper is a meta

15 Chapter 2 2.5 Clear CMOS (JP3)This jumper is used to erase CMOS data and reset system BIOS informa-tion.The procedure for clearing CMOS is:1. Tur

PCM-9586 User’s Manual 162.7 IDE, CDROM hard drive connector (CN5, CN6) The PCM-9586 provides 2 IDE channels which you can attach up to four Enhanced

17 Chapter 2 2.9 Floppy drive connector (CN8)You can attach up to two floppy drives to the PCM-9586’s on-board con-troller. This is useful for noteb

PCM-9586 User’s Manual 182.10 Parallel port connector (CN4)Normally, the parallel port is used to connect the card to a printer. The PCM-9584 include

19 Chapter 2 2.13 Power connectors (CN10,CN15)2.13.1 ATX power connector, +5V (CN15) Supplies main power to the PCM-9586 (+5V) and to devices that r

iiiPacking List Before you begin installing your card, please make sure

PCM-9586 User’s Manual 202.15.2 CD audio-in connector (CN18) All CD-ROM drives can provide analog audio signal output when used as a music CD player.

21 Chapter 2 plays. Users can connector to either an 18, 24, 36bit LVDS LCD with CN162.17.3 DVI LCD panel connector(CN7) Digital Visual Interface (DV

PCM-9586 User’s Manual 222.19.2 Network bootThe Network Boot feature can be utilized by incorporating the Boot ROM image files for the appropriate net

23 Chapter 3 CHAPTER 3Software ConfigurationThis chapter details the software con-figuration information. It shows you how to configure the card to m

PCM-9586 User’s Manual 24Chapter 3 Software Configuration3.1 IntroductionThe PCM-9586 system BIOS and custom drivers are located in a 512 Kbyte, Fla

25 Chapter 3 3.2 Connections to Three Standard LCDsThe following tables illustrate typical LCD connection pinouts for the PCM-9586.3.2.1 LG LM150X06

PCM-9586 User’s Manual 263.3 Installing the CSI Utility1. Insert the driver CD into your systemís CD-ROM drive. In a few seconds, the cd main menu ap

27 Chapter 3 3. Click "Yes" when you see the following message.4. Click "Next" when you see the following message.

PCM-9586 User’s Manual 285. When the following message appears, click "Finish" to complete the installation and restart Windows.

29Chapter 4 Ducks that Need Love!4Award BIOS SetupThis chapter describes how to set BIOS configuration data.CHAPTER

PCM-9586 User’s Manual iv FCCThis device complies with the requirements in part 15 of the FCC rules: Operation is subject to the following two condi-t

PCM-9586 User’s Manual 30Chapter 4 Award BIOS Setup4.1 System test and initializationThese routines test and initialize board hardware. If the routi

314.2 Award BIOS setupAward’s BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of informat

PCM-9586 User’s Manual 324.2.2 Standard CMOS Features setupWhen you choose the Standard CMOS Features option from the Initial Setup Screen menu, the s

334.2.3 Advanced BIOS Features setupBy choosing the Advanced BIOS Features Setup option from the Initial Setup Screen menu, the screen below is displa

PCM-9586 User’s Manual 344.2.4 Advanced Chipset Features setupBy choosing the Advanced Chipset Features option from the Initial Setup Screen menu, the

354.2.6 Power Management SetupBy choosing the Power Management Setup option from the Initial Setup Screen menu, the screen below is displayed. This sa

PCM-9586 User’s Manual 364.2.8 PC Health StatusThe PC Health Status option displays information such as CPU and moth-erboard temperatures, fan speeds,

374.2.10 Load Optimized DefaultsLoad Optimized Defaults loads the default system values directly from ROM. If the stored record created by the Setup p

PCM-9586 User’s Manual 383. At the “Confirm Password” prompt, retype the desired password, then press <Enter>.4. Select Save to CMOS and EXIT, t

394.2.12 Save & Exit SetupIf you select this option and press <Y> then <Enter>, the values entered in the setup utilities will be reco

vAdditional Information and Assistance 1. Visit the Advantech web site at www.advantech.com where you can find the late

PCM-9586 User’s Manual 40

41 Chapter 5 CHAPTER 5PCI GraphicIntroductionInstallation of PCI Graphic drivers -for Windows 98/2000/XPFurther information

PCM-9586 User’s Manual 42Chapter 5 PCI Graphic Setup5.1 IntroductionThe PCM-9586 has an onboard PCI/AGP flat panel/VGA interface. The specifications

43 Chapter 5 5.1.4 Dual/Simultaneous DisplayThe PCM-9586 uses a Intel 852GM controller that is capable of provid-ing simultaneous dual view display o

PCM-9586 User’s Manual 44Figure 5.1: Selecting Display Settings

45 Chapter 5 5.2 Installation of the PCI Graphic driverComplete the following steps to install the PCI graphic driver. Follow the procedures in the

PCM-9586 User’s Manual 46

47 Chapter 5

PCM-9586 User’s Manual 485.3 Further InformationFor further information about the AGP/VGA installation in your PCM-9586, including driver updates, tr

49 Chapter 6 CHAPTER 6Audio SetupThe PCM-9586 is equipped with an audio interface that records and plays back CD-quality audio. This chapter provides

PCM-9586 User’s Manual vi

PCM-9586 User’s Manual 50Chapter 6 Audio Setup6.1 IntroductionThe PCM-9586's on-board audio interface provides high-quality stereo sound and FM

51 Chapter 6 6.2.2 Windows 9x/2000/Me/XP driversStep 1. To install Audio driver for Windows 98/2000/XP, please run the set up wizard "Install

PCM-9586 User’s Manual 52Step 3. In the following Hardware Update Wizard window, click "Fin-ish" for Windows to complete audio driver insta

53 Chapter 7 CHAPTER 7LAN Configuration• Introduction• Features• Installation of Ethernet Driver for- Windows 2000 Drivers Setup Steps- Windows NT

PCM-9586 User’s Manual 54Chapter 7 PCI Bus Ethernet Interface7.1 IntroductionThe PCM-9586 is equipped with a high-performance 32-bit Ethernet chipse

55 Chapter 7 7.3.1 Installation for Windows 98&20001. a.Select "Start", "Settings". "Control Panel". b. Do

PCM-9586 User’s Manual 56

57 Chapter 7 3. Choose Hardware Device “Ethernet Controller”

PCM-9586 User’s Manual 584. Insert the CD into D: drive a. Fill in the Find the LAN chipset folder at the directory of PCM- 9586 win200

59 Chapter 7 5. Choose the "Intel(R) GD82559ER PCI Adapter" item. Click “Next”

vii Table of ContentsContentChapter 1 Introduction ...21.1 Introduction ...

PCM-9586 User’s Manual 606. a. Make sure the configurations of relative items are set correctly

61 Chapter 7 7.4 Further informationIntel website: www.intel.comAdvantech websites: www.advantech.com www.advantech.com.t

PCM-9586 User’s Manual 62

63 Appendix A AppendixAProgramming the GPIO and Watchdog TimerThe PCM-9586 is equipped with a watchdog timer that resets the CPU or generates an inte

PCM-9586 User’s Manual 64Appendix A Prog. GPIO & W’dog TimerA.1 Supported GPIO RegisterBellow are detailed description of the GPIO addresses and

65 Appendix A A.1.2 GPIO Example program-1------------------------------------------------ Enter the extended function mode, interruptible double-wr

PCM-9586 User’s Manual 66OUT DX,ALMOV DX,2FHMOV AL,??H; Put the output value into AL ??HOUT DX,AL ------------------------------------------ Exit ext

67 Appendix A A.2 Watchdog programmingBellow is a sample of programming code for controlling the Watchdog Timer function.---------------------------

PCM-9586 User’s Manual 68MOV DX,2EH MOV AL,F6HOUT DX,ALMOV DX,2FHMOV AL,05H; Set 5 secondsOUT DX,AL ;------------------------------------------; Exit

69 Chapter B AppendixBPin AssignmentsThis appendix provides specialized information regarding:• CPU Fan Power Connector• Ethernet 10/100Base-T Connec

PCM-9586 User’s Manual viii2.16 COM port connector (CN11) ... 202.17 VGA/LVDS interface connections (CN13, CN16

PCM-9586 User’s Manual 70Appendix B Pin AssignmentsB.1 CPU fan connector (CN10) Table B.1: CPU Fan connector(CN10)Pin Signal1GND2 +12V3 SPEED DETEC

71 Chapter B B.2 Ethernet 10/100Base-T Connector (CN23)Table B.2: Ethernet 10/100Base-T connector (CN23)Pin Signal1 VCC_LAN2ACTLED3RX+4RX-5LILED6GND

PCM-9586 User’s Manual 72B.3 Ethernet 10/100/1000 BASE-T connector (CN2)Table B.3: Ethernet 100/1000-T connector (CN2)Pin Signal1NC2NC3RJ45 PIN74RJ45

73 Chapter B B.4 Ethernet LED connector(CN1)B.5 ACLink audio connector (CN14)Table B.4: Giga bit Ethernet LED (CN1)Pin Signal1VCC2GND3LINK4ACT5LINK

PCM-9586 User’s Manual 74B.6 CD-IN Connector (CN18)B.7 ATX Main Power Connector (CN15)Table B.6: CD-IN Connector (CN18)Pin Signal1 CD_L2GND3GND4 CD_

75 Chapter B B.8 Keyboard and PS/2 Mouse Connector (CN19)Table B.8: Keyboard and mouse connector (CN19)Pin Signal1 KB CLOCK2 KB DATA3MS CLOCK4GND5+5

PCM-9586 User’s Manual 76B.9 Floppy Disk Drive Connector (CN8)Table B.9: Floppy Disk Drive Connector (CN8)Pin Signal Pin Signal1 Vcc (5 V) 2 INDEX3 V

77 Chapter B B.10 IDE Hard Drive Connector (CN5, CN6) Table B.10: IDE HDD connector (CN5, CN6)Pin Signal Pin Signal1Reset 2GND3D7 4D85D6 6D97D5 8D

PCM-9586 User’s Manual 78B.11 Parallel Port Connector (CN4) Table B.11: Parallel Port Connector (CN4)Pin Signal Pin Signal1STROBE* 2AUTOFD*3D0 4ERR

79 Chapter B B.12 Front Panel LED (CN3) Table B.12: 1 HDD LED+ Pin Signal Pin Signal1 HDD LED 2 HDD LED -3 Power LED+ 4 POWER LED-5 SUS LED+

ix Table of ContentsChapter 5 PCI Graphic Setup...425.1 Introduction ...

PCM-9586 User’s Manual 80B.13 USB Connector (CN25,26,27) B.14 SIR Connector (CN24)Table B.13: USB Connector (CN25,26,27)Pin Signal Pin Signal1+5

81 Chapter B B.15 TV Out Connector (CN12)

PCM-9586 User’s Manual 82B.16 LCD Inverter Backlight Connector (CN17) B.17 CRT Display Connector (CN13) Table B.16: Inverter Backlig

83 Chapter B B.18 LVDS Connector (CN16) Table B.18: LVDS Connector (CN16) Pin Signal Pin Signal1 LCD VDD 2 LCD VDD 3GND 4GND5 LCD VDD 6 LCD VDD

PCM-9586 User’s Manual 84B.19 COM Port Connector (CN11) Table B.19: COM Port Connector (CN11)Pin Signal Pin Signal1 COM1 DCD 2 COM1 DSR3 COM1 R

85 Chapter B B.20 CompactFlash Card Connector (CN20) Table B.20: CompactFlash Card Connector (CN20)Pin Signal Pin Signal1GND 2SDD33 SDD4 4 SDD55 SD

PCM-9586 User’s Manual 86B.21 GPIO Connector (CN9)Table B.21: GPIO Connector (CN9)Pin Signal1 GPIO02 GPIO43 GND4GND5 GPIO16 GPIO57VCC8NC9 GPIO210 GP

87 Chapter B B.22 TMDS Connector(CN7) Table

PCM-9586 User’s Manual 88B.23 Mini PCI ConnectorTable B.23: Mini PCIPin Signal Pin Signal1 TIP Key 2 RING Key3 8PMJ-33, 4 4 8PMJ-13, 45 8PMJ-63, 4

89 Appendix C AppendixCSystem AssignmentsThis Appendix contains information of a detailed nature: It includes:• System I/O ports• 1st MB memory map•
