Mini-ITX Form Factor

Intel

Desktop Board

DN2800MT Innovation Series

HDMI* and VGA ports. Supporting a USB

Solid-State Drive keep-out zone design and

mini-SATA PCI Express* Mini-Card connector,

the Intel Desktop Board DN2800MT is ideal

for diskless usage model by integrating

the Solid-State Drive onto the board.

The Intel Desktop Board DN2800MT is a

mini-ITX form factor board. Backward-

compatible with ATX and microATX, this

form factor allows you to build energy-

efcient and small form factor solutions.

This board offers simple, affordable, and

Internet-centric computer designs in a

compact 170mm x 170mm size; perfect

for an ultra-small form factor system with

one-litre type chassis or all-in-one chassis.

with the previous-generation entry-level

desktop PC. This board provides exibility

and upgradability with two single-channel

SODIMM connectors for DDR3 1066 /

800 MHz memory support (4 GB

max).

The use of SODIMM memory modules

delivers greater performance and power

efciency. The revolutionary two-chip

layout continues to enable lower power

consumption and saves 70 percent of its

board layout size. This results in a board

that has better heat ow with the fanless

thermal solution.

The Intel Desktop Board DN2800MT

provides enhanced features such as

10/100/1000 Mb/s integrated LAN, inte-

grated four-channel Intel® High Denition

Audio, and dual display capability with

The Intel® Desktop Board DN2800MT is the

latest Innovation Series board that optimizes

the performance of the Intel® Atom™ pro-

cessor N2800 and the Intel® NM10 Express

Chipset by delivering new-generation

technologies, value-added features, and

easy integration. The Intel Desktop Board

DN2800MT board is suitable for ultra-

small form factor or all-in-one systems

that require dual independent display

capabilities in a fanless system.

The Intel Desktop Board DN2800MT fea-

tures the new integrated dual-core 1.86

GHz Intel Atom processor N2800. This

processor supports the Intel® Graphics

Media Accelerator 3650, an improved

graphics core supporting high-denition

video playback capabilities compared

PRODUCT BRIEF

Intel® Desktop Board DN2800MT

Innovation Series

1 2 3 4

Summary of Contents

Page 1 - DN2800MT Innovation Series

Mini-ITX Form FactorIntel® Desktop Board DN2800MT Innovation SeriesHDMI* and VGA ports. Supporting a USB Solid-State Drive keep-out zone design and mi

Page 2

2Intel® Desktop Board DN2800MT Innovation SeriesThe boxed Intel® Desktop Board DN2800MT solution includes:• ATX 2.2 compliant standard-height I/O shie

Page 3 - Features and Benets

36.7” (170mm)6.7” (170mm)7 8123495Intel® Desktop Board DN2800MT Innovation Series Features and Benets111561012 9 Eight Hi-Speed USB 2.0 ports: Four

Page 4 - Technical Specications

PROCESSOR Processor Support •Intel®Atom™processorN2800(dual-core/1.86GHz/ Intel®Hyper-ThreadingTechnology3/512KBx2L2 cache)CHIPSE
