PCM-6896Intel 815E compact board with PCIslot, Audio, LAN, compact flash, 4COM ports, PC/104 & PC/104 Plus

1GeneralInformationThis chapter gives background informa-tion on the PCM-6896.Sections include:• Card specifications• Card layout and dimensionsCHAPTE

Installing VGA for Windows 2000®==>Place the Driver CDROM into your CDROM drive. Pull upthe CDROM file on your screen..==>Click on VGA folder==

Installing Audio for Windows 2000®==>Place the Driver CDROM into your CDROM drive. Pull upthe CDROM file on your screen..==>Click on Sound fold

Installing LAN for Windows 2000®==>Place the Driver CDROM into your CDROM drive.==>Click on Start button==>Click on Settings button==>Clic

AAEON’s new compact size board PCM-6896 targets high-end multime-dia and networking applications. This board is supported by IntelCeleron and Pentium

Features• Supports both Intel FC-PGA Pentium III and Celeron CPU’s• High Speed Micro AGP 2X for VGA function onboard• One 10/100 Base-T Fast Ethern

SpecificationsCPU: Intel FC-PGA 370-pin Pentium III and Celeron CPU’s (with systembus frequencies of 66/100/133MHz)CPU Socket: Intel socket 370BIOS:

IrDA port: Support SIR and CIRConnector: One 6-pin (2.54mm) pin headerKB/PS2 Mouse connector: A 7-pin (4*2-1) header supports PC/ATKeyboard and PS/

Audio Interface:Chipset: 815ECodec: ALC200 or compatibleInterface: One 14-pin (2.00mm) pin header for MIC in, line in, line out,speaker out, CD-in.

SDD InterfaceOne 32-pin DIP socket supports M-Systems DiskOnChip 2000 series up to288MB.Mechanical and EnvironmentalPower Supply voltage: +5V, +12V,

Board LayoutCN22PCI1CN4JP1CN14JP6CN17CN11JP4CN20CN5CN7CN15CN6CN21JP10CN3JP3JP2JP8CN2CN25JP5CN10JP7CN18CN13CN19CN16CN1CN9JP9CN12CN24

Board Dimensions

CHAPTER2InstallationThis chapter provides information regardingPCM-6896 hardware, including instructions onsetting jumpers and connecting peripherals,

Copyright Notice This document is copyrighted, 2001. All rights are reserved. The original manufacturer reserves the right to ma

Safety precautionsWarning! Always completely disconnect the power cord fromyour chassis whenever you are working on it. Do notmake connections while t

Installing A CPUTo install the CPU, follow the instructions that came with it. If nodocumentation was provided, the general procedures for installinga

111113333322222 Open Closed Closed 2-3 Open Closed Closed 2-31 2 3Setting jumpersYou configure your card to match the needs

Installing DRAM (DIMMs)System MemoryPCM-6896 contains one socket for 168-pin dual in-line memorymodule (DIMM). The socket uses 3.3 V unbuffered synchr

Location of Jumpers & ConnectorsCN22PCI1CN4JP1CN14JP6CN17CN11JP4CN20CN5CN7CN15CN6CN21JP10CN3JP3JP2JP8CN2CN25JP5CN10JP7CN18CN13CN19CN16CN1CN9JP9CN1

List of JumpersJumpers allow users to manually customize system configurationsto their suitable application needs.The following tables list the functi

List of ConnectorsConnectors on board access link to external devices such as harddisk drives, a keyboard, VGA, or floppy drives.The following consis

Clear CMOS Selection (JP1)Safety precautions in setting up clear CMOS must be taken, alwaysplace jumper on protect mode. In clearing CMOS, place jumpe

(JP2) & (JP3) For COM3 & COM4 Selec-tion+12V 1 3 5 2 4 6+5VRI (default) 1 3

Speaker Out and Line out (JP4)Line Out 1 3 5 2 4 6Speaker Out (default) 1 3 5 2 4 6

Packing ListBefore you begin installing your card, please make sure that thefollowing materials are included:• 1PCM-6896 Intel 815E all in one CPU Ca

RS-232/422/485 COM 2 (JP8), (JP7)Setting*RS-232 (default)1 4 7 10 3 6 9 12RS-485RS-4221 4 7 10 3 6 9 12 1 4 7 10 3 6 9 12

CPU/SDRAM Speed Select (JP9)Auto Detect Auto Detect 1 2 3 4 5 6 7 8CPU/66MHz S

DiskOnChip socketThe DiskOnChip 2000 family of products provides a single chipsolid-state flash disk in a standard 32-pin DIP package. TheDiskOnChip 2

DiskOnChip (DOC) 2000 InstallationWhen the DOC is installed correctly, a DOC will work like an HDDor an FDD. To install the DOC on the mainboard, fol

DiskOnChip Address Selection (JP10)The DiskOnChip 2000 family of products provides a single chipsolid-state flash disk in a standard 32-pin DIP packag

CPU and System Fan Power Connector (CN1 & CN24)One 3-pin plug in and error free onboard connectors are locatedaccessibly for trouble-free connecti

USB Connector (CN5) & (CN6)PCM-6896 is equipped with four USB ports onboard .It acquires the new generation of plug and play ( Hot Plugging )feat

IDE Hard Drive Connectors (CN7)If customers have (Neccessity) to use ATA-100 HDD andATA-33 CABLE you must alter two settings in the AwardBIOS. The tw

IDE Hard Drive Connector (CN7)If customers have (Neccessity) to use ATA-100 HDD andATA-33 CABLE you must alter two settings in the AwardBIOS. The two

ATX Power Connector (CN11)For ease and reliability, a standard 20-pin ATX power supply con-nector is onboard. Which also provide positive plugging thr

A Message to the CustomerAAEON Customer ServicesEach and every AAEON product is built to the most exactingspecifications to ensure reliable performanc

Digital Visual Interface Connector (CN12)Digital Visual Interface Connector (CN12)Pin Signal Pin SignalA1 FTCLK0 B1 FTD0A2 FTCLK1 B2 FTD1A3 CRT HSYNC

Keyboard and Mouse Connector (CN13)The PCM-6896 provides a keyboard connector which supportsboth a keyboard and a PS/2 style mouse. In most cases, esp

A standard conventional D-sub connector is equipped to interfacewith conventional CRT displays. Refer to pin definitions as follows:VGA Display Connce

Parallel Port Connector (CN16)The mainboard is designed to support one parallel port. Port 1connector (CN16) also designated as LPT1 is a standard 25-

100 Base-Tx Ethernet Connector (CN17)PCM-6896 is outfitted with a standard RJ-45 LAN connector. Withsupport from Intel 815E chipset using either 10Mbs

Floppy drive connector (CN19)You can attach up to two floppy drives to the mainboard controller.You can use any combination of 5¼" (360 KB and 1.

Floppy Drive Connector (CN19)Pin Signal Pin Signal1 GND 2 DENSITY SELECT3 GND 4 N.C.5 GND 6 N.C.7 GND 8 INDEX9 GND 10 MOTOR A11 GND 12 DRIVE SELECT B1

Digital I/O Connector (CN20)PCM-6896 offers 4-pair of digital I/O functions. With the input andoutput consisting of the following: Input 801H; GPI20 [

Audio Out Connector 1 Watt (CN22)Audio Out Connector 1 Watt (CN22)Pin Signal1 OUT L+2 OUT L-3 OUT R+4 OUT R-CN25 Wake On Lan (Pins 1-5)(CN25) Wake On

Compact Flash ConnectorPin Signal Pin Signal1 GND 26 GND2DATA3 27DATA113 DATA4 28 DATA124 DATA5 29 DATA135 DATA6 30 DATA146 DATA7 31 DATA157 CS#1 32 C

Product WarrantyAAEON warrants to you, the original purchaser, that each of itsproducts will be free from defects in materials and workmanship fortwo

3Award BIOS SetupThis chapter describes how to configurethe BIOS for the PCM-6896 board.CHAPTER

Starting setupThe Award BIOS is started immediately when you first turn on thecomputer. The BIOS reads, system configuration information inCMOS RAM an

Getting helpPress F1 to pop up a small help window. On screen informationdescribes the appropriate keys to use and the possible selectionsfor the high

Setup keysThese keys helps you navigate in Setup:Up arrow Move to previous itemDown arrow Move to next itemLeft arrow Move to the item in the left han

Main Setup MenuStandard CMOS FeaturesUse this menu for basic system configuration. (Date, time, IDE, etc.)Advanced BIOS FeaturesUse this menu to set t

PnP/PCI ConfigurationThis entry appears is your system supports PnP/PCI.PC Health StatusThis menu allows you to set the shutdown temperature for yours

Standard CMOS FeaturesThis standard setup menu allows users to configure systemcomponents such as the date, time, hard disk drive, floppy drive,displa

If you do not want to select drive type AUTO, other methods ofselecting the drive type are available:1.Match the specifications of your installed IDE

- LBA (Logical Block Addressing): During drive access, the IDE controller transforms the data address described by sector, hea

Halt OnDuring the power-on-self-test (POST), the computer stops if theBIOS detects a hardware error. You can tell the BIOS to ignorecertain errors dur

NoticeDear Customer, Thank you for purchasing the PCM-6896 board. This user'smanual is designed to help you to get the most out of the PCM

Extended MemoryAbove the 1-MB boundary. Early IBM personal computers couldnot use memory above 1 MB, but current PCs and their softwarecan use extende

Advanced BIOS FeaturesThe displayed configuration is based on the manufacturer's SETUPDEFAULTS settings.Virus WarningWhen enabled, you receive a

CPU Internal Cache/External CacheCache memory is additional memory that is much faster thanconventional DRAM (system memory). CPUs from 486-type on up

Swap Floppy DriveThis field is effective only in systems with two floppy drives.Selecting enabled assigns physical drive B to logical drive A, andphys

Typematic Rate Setting- Key strokes repeat at arate determined by the keyboard controller. Whenenabled, the typematic rate and typematic delay can b

HDD S.M.A.R.T CapabilityHard disk drives have built in problem detectioncapability. If a foreseen problem is about to take place,the compute

Advanced Chipset FeaturesSDRAM CAS Latency TimeWhen synchronous DRAM is installed, the number of clock cycles ofCAS latency depends on the DRAM timing

SDRAM RAS Precharge TimeIf an insufficient number of cycles is allowed for the RAS to accumulate itscharge before DRAM refresh, the refresh may be inc

AGP Graphics Aperture SizeSelect the size of Accelerated Graphics Port (AGP) aperture. The apertureis a portion of the PCI memory address range dedic

RAS-to-CAS OverrideThis item allows you to insert a timing delay between theCAS and RAS strobe signals, used when Onboarddisplay cache is written to,

ContentsCopyright Notice...2Packing List...

Integrated PeripheralsOn-Chip Primary PCI IDEThe system chipset contains a PCI IDE interface with support fortwo IDE channels. Select Enabled to activ

IDE Primary/Secondary Master/Slave UDMAUltra DMA/33 implementation is possible only if your IDE harddrive supports it and the operating environment in

Onboard FDC ControllerSelect Enabled if your system has a floppy disk controller (FDC)installed on the system board and you wish to use it. If you ins

Onboard Serial Ports (1, 2,3,4)Normally, the main board’s I/O chips will occupy a certain portionof memory space. For each I/O device the computer pr

Watch Dog TimerYou can enable the system watch-dog timer, a hardware timer thatgenerates either an NMI or a reset when the software that itmonitors do

Power Management SetupACPI FunctionThis item allows you to enable/disable the Advanced Configura-tion and Power Management (ACPI). The Choices: Enabl

)tluafeD(elbasiD.sedomruofllaelbasiD.tnemeganamrewopoNgnivaSrewoP.niM1=edomezoD.nemeganamrewopmuminiM=edomdnepsuS.ruoh1=edomybdnatS.ruoh.setunim51=nwo

Video Off In SuspendAfter the selected period of system inactivity, the chipset enters ahardware suspend mode, stopping the CPU clock and possiblycaus

Power On By RingAn input signal on the serial Ring Indicator (RI) line (in otherwords, an incoming call on the modem) boots the system from asoft off

PnP/PCI ConfigurationsPnP OS InstalledThis item allows you to determine whether that PnP OS is installedor not. The choice: Yes or NoReset Configura

PC/104 Plus Voltage Select (JP6)...29COM 2 Setting (JP8 &JP7)...30CPU/SDRAM Setting (JP9)

PC Health StatusShutdown TemperatureYour system can be configured to shutdown once reaching acertain temperature. To protect your system from overhea

Frequency/Voltage ControlAuto Detect DIMM/PCI CLKThis item allows you to enable/disable auto detect DIMM/PCIclock. The choices: Enable/DisableSpread

Load Fail-Safe DefaultsLoad Fail-Safe DefaultsWhen you press <Enter> on this item you get a confirmation dialogbox with a message similar to:Loa

Load Optimized DefaultLoad Optimized DefaultWhen you press <Enter> on this item you get a confirmation dialogbox with a message similar to:Load

Set Supervisor PasswordWhen you select this function, a message appears at the center ofthe screen:ENTER PASSWORD:Type the password, up to eight chara

Set User PasswordWhen you select this function, a message appears at the center ofthe screen:ENTER PASSWORD:Type the password, up to eight characters,

Save to CMOS and EXITSave to CMOS and EXITPressing <Enter> on this item asks for confirmation:Save to CMOS and Exit (Y/N)?Pressing “Y” stores th

Quit without SavingExit Without SavingPressing <Enter> on this item asks for confirmation:Quit Without Saving (Y/N)?This allows you to exit Set

CHAPTER This PCM-6896 is equipped with an audio VGA and LAN interface. This chapter provides instructions for installing the softwaredrivers on these

Installing Drivers Notice: AttentionFirst if using operating systems such as Windows98/2000 ® a chipset driver must be installed before VGA,LAN or

Chapter 4: Driver Installation ...89Notice: Attention...90Chips

Installing Chipset Driver for Windows 95/98/2000®The chipset driver must be installed in order toproceed to LAN, VGA and AUDIO drivers.==>Place the

Installing Ultra ATA Storage Driver for Windows 95/98/2000®The Ultra ATA Storage Driver must be installed inorder to use Windows 98/2000 ® operating s

Installing LAN for Windows 95/98®==>Place the Driver CDROM into your CDROM drive.==>Click on Start button==>Click on Settings button==>Cli

Installing VGA for Windows 95/98®==>Place the Driver CDROM into your CDROM drive. Pull upthe CDROM file on your screen..==>Click on Intel folde

Installing Audio for Windows 95/98®==>Place the Driver CDROM into your CDROM drive. Pull upthe CDROM file on your screen..==>Click on Sound fol

Installing Security Driver for WindowsNT® Please perform this procedure first==>Place the Driver CDROM into your CDROM drive. Pull upthe CDROM fil

Installing Ultra ATA Storage Driver for WindowsNT®The Ultra ATA Storage Driver must be installed inorder to use Windows NT ® operating systems.==>P

Installing VGA for Windows NT®==>Place the Driver CDROM into your CDROM drive. Pull upthe CDROM file on your screen..==>Click on VGA folder==&g

Installing Audio for Windows NT®==>Place the Driver CDROM into your CDROM drive. Pull upthe CDROM file on your screen..==>Click on Sound folder

Installing LAN for Windows NT®==>Place the Driver CDROM into your CDROM drive.==>Click on Start button==>Click on Settings button==>Click
